3. Insert the Fischer screw plugs into the holes and tighten the screws provided.
NOTE: Tighten the screws securely. Do not insert the screws into the Fischer plugs entirely - leave around 10 mm free.
4. Mount the appliance on the wall (figure 3).
Ensure that the holes on the rear of the appliance are directed towards the two screws, push the fan heater backwards
onto the wall then downwards until it lies in a stable position.
CONTROL PANEL AND LED DISPLAY ON THE APPLIANCE
TIMER LED
TEMPERATURE
°C LED
ROOM
TEMPERATURE
DISPLAY
ECO Mode LED
energy saving (1000
W)
WEEKLY
TIMER LED
OPEN WINDOWS
Mode LED
TIMER
BUTTON
Figure 1 Figure 2 Figure 3
Fischer
ON/OFF BUTTON
F BUTTON
Function selection
COMFORT Mode LED
Maximum heat
