Argos 338/7005 - Fittings; Tools Required; Ruler

4
Please check you have all the ttings listed below
Ruler - Use this ruler to help correctly identify the screws
Tools required
Note: The quantities below are the correct amount to complete the assembly. In some cases more ttings
may be supplied than are required.
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170
105
Components - Fittings
0 1 0 20 30 40 50 60 70 80 90 100 110 120 130 140 150
0 1 2 3 4 5 6
Phillips screwdriver
(medium & large)
Flatblade screwdriver
(medium)
Small
hammer
Ruler/tape
measure
Drill
Eye protection
(when using a
hammer or glue)
7mm Suitable drill bit
(for use with wall plug)
The screws length is measured from the head to the point (30mm screw shown).
42mm Bolt x 10
H
B
D
E
G
F
J
I
K L
N O
A C
M
Q RP
T
U
S
V
Sprint washer x 10
X
Allen key x 1
50mm Screw x 84
30mm Screw x 17
14mm Screw x 14
12mm Screw x 6
20mm Screw x 2
15mm Screw x 28
(24 pcs screws are
included in the door hinges
bag, 4 pcs for rail support)
(This screw is included in
the runners bag)
12mm Screw x 18
39mm Locking pin x 14
15mm Locking nut x 212mm Locking nut x 12 30mm Dowel x 1
Door hinge x 4 Runner x 6 Rail Support x 2
Plastic support x 7 Door Stop x 1 Handle x 5
Clothes rail x 1
Ladder step x 5Ladder post x 2
W
Door pad x 4
Y
Screw Cover x 40
(This bolt is included
in the ladder bag)
