Argos 338/7005 - Assembly; Fitting the Track


Step 1
Fitting the track
a:
b:
b: Slide top of Runners
forward and fix as
shown using Screws .
N
Note: The front part of
the runner should be
approximately 1.7cm from
the front edge of the panel.
G
It would be useful to ask
someone to help you at
this stage.
5
Important:
Because of the
size of this unit we
recommend that it
is built in the room
intended for use.
Warnung:
Be aware of the
danger of young
children under six
years old falling
from the upper
bunk. Top bunk
beds are not
recommended for
children under six
years old.
Complies BS EN
747-1 and BS EN
747-2:2012.
Note: There are many
different kinds of screws
and parts. Ensure you
check before assembly.
Silde top of the Runners
back.
Use screws to fix the
Runners on the Centre
right side panel .
a: Position Runners in
front edge of the Centre
right side panel .
Continued on next page.
