Argos 601/4650 - Stage 4 - Fitting the Legs

7
Assembly Instructions
Step 7
Step 8
NOTE: It would be
useful to ask someone
to help you at this step.
Stage 4 – Fitting the Legs
4
Insert the Baseplate
into the Leg Poles
Then insert the Leg
Poles into the unit.
Ensure all the poles are
fully inserted and secure.
See fig. 9.
Attach the Gazebo
Cover’s Hooks into holes
on the Leg Poles .
Tighten by moving the
Hook to a lower hole.
See fig.12.
6#
6#
6#
J
Fig.9
4
4
4
4
6#
6#
6#
6#
6#
5#
Fig.10
Fig.12
Hook
4
6#
