Assembly Instructions
Assembly Instructions
Stage 2 – Wall MountingStage 1 – Fitting the Shelf
fig. 1 fig. 2
fig. 4
fig. 5
BS 7449:1991
Model / Catalogue Number: 832/2522
Retailer: ARG
Retailer address: 
489-499 Avebury Boulevard, Saxon
Gate West, Central Milton Keynes,
Bucks, MK9 2NW
IMPORTANT: When drilling into
walls always check that there
are no hidden wires or pipes etc.
Make sure that the screws and
wall plugs supplied are suitable
for supporting the unit. Consult
a qualified tradesperson if you
are not sure.
fig. 3
NOTE: This unit contains
tempered glass of nominal
thickness of 5mm and complies with
Class C of BS 6206. If the glass is
chipped or broken, replace with glass
of the type described on this label.
Consult the furniture retailer or agent
with regard to obtaining a
manufacturing specification of the
shape for replacement glass quoting
the model number, and batch number
or date of manufacture of this item.
NOTE: It would be useful to ask
someone to help you at this
stage.
WALL MOUNTING: Hold the unit
against the wall in the desired
location and check if it is
horizontal. Mark the wall to
indicate where to drill the holes.
See fig. 4.
1. Insert the Plastic Plugs D onto
the end of Long Tube C and
Short Tube G. Ensure they are
well fitted.
See fig. 1 and 2.
2. Use Screw A to fix the Short
Tube G onto the Long Tube C.
See fig. 3.
1. Use the Wall Plug B to fit to the
hole. Then screw in the Screws C
through the unit into the Wall Plugs.
See fig. 5.
3. Use the same method as in fig.
1 to 3 fix the other Tubes.
G
D
C
D
G
C
A
C
B
