Argos Malibu - Prepare Filer Right Side and Join Shelf

Finished
front edge
E
E
Assembly Instructions
14
Step 25
Finished
front edge
Join the filer right
side and fixed shelf
Push the fixed shelf
onto the filer right side
. and secure it using 2
screws .
7
4
7
4
E
Finished
front edge
J
Q
J
Q
C
C
Finished
front edge
Finished
front edge
I
I
U b
I
U b
I
Finished front edge
I
1st
screw
2nd
screw
I
3rd
screw
U b
Finished front edge
H
H
J
Prepare the filer right
side
a: Place a runner on
the filer right side as
shown. Slide back the
top of runner and use the
2nd hole from the front
to fit the 1st screw .
b: Slide the runner
back the other way and
fit the 2nd screw into
the corresponding hole
in the filer right side .
Fit the runner to the
filer right side .
The 1st screw uses
the 2nd hole in from the
front of the runner .
The 2nd and 3rd screws
use the holes that lines
up with the other panel
holes.
Fit a screw into the
2nd hole in at the top of
the runner .
Insert 2 large locking
nuts into the filer right
side .
4
J
J
4
4
Q
Q
C
4
U b
U b
I
H
U b
a:
b:
Step 26
4
4
