Argos Mix - Attaching Chest Top and Back Panels

Assembly Instructions
14
Step 23
9
8
10
Fit the top
Push the top onto
the side panels and
. .
Use a screwdriver to
tighten the 2 large
locking nuts fitted to
the inside of the side
panels and .
Note: Turn the large
locking nuts as far as
they will go - more than
1/2 a turn.
10
8
8 9
F
F
y
y
x
x
The measurement from top corner X to bottom corner X must be
equal to the measurement from top corner Y to bottom corner Y
a:
b:
Step 24
15
9
D
Fit the back
a: Square up the unit by
making sure that
measurement x to x
equals y to y.
b: Place the back
onto the unit.
Nail around the
outside edges of the
back .
Note: Nails should
be spaced about 150mm
apart.
Stand the unit up for
the next step.
15
D
15
