7.- FITTING THE REFLECTORS & BELL
TOOLS NEEDED
A
First fully release the securing screws as shown
(an-clockwise)
C
Once these are in place, replace the screws and ghten by turning clockwise using a cross-head screwdriver
B
Wrap the bell around the handlebar as shown, remembering
to put it in a place where you can reach it easily whilst riding.
Then wrap the white reflector around the handlebar near the
centre, and wrap the red reflector in the same way around
the saddle post.
BELL RED REFLECTOR WHITE REFLECTOR
HANDLEBAR
(Bell and White Reflector)
SADDLE
(Red Reflector)
CROSS HEAD
SCREWDRIVER
10
IF YOU ARE EXPERIENCING ANY PROBLEMS PLEASE CALL 0161 813 1745 BEFORE RETURNING BIKE TO STORE
