Components - Parts
Please check you have all the parts listed below
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more
fittings may be supplied than are required.
1
Seat
(41.5 x 10 x 35cm)
2
Swivel plate
(16 x 16 x 2cm)
5
Stretcher
(Ø1.9 x 35 x 35cm)
3
Upper leg
(Ø2.2 x 72 x 47cm)
4
Lower leg
(Ø2.2 x 72 x 47cm)
A
M6 x 30mm Bolt x 8
105 150 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120 125 130 135 140 145 150 155 160 165 170
Ruler - Use this ruler to help correctly identify the screws
C
M6 x 18mm Bolt x 4
D
Nut x 5
F
Spanner x 1
B
M6 x 22mm Bolt x 1
G
Allen key x 1
E
Washer x 8
Components - Fittings
If you have damaged or missing components,
call the Customer Helpline: 08456 400800
