Assembly Instructions
10
Step 10
Step 11
Attaching panels
Put drop of glue g into
the 2 holes of left side 1
and the 2 holes of right side
2.
Position left side 1 and
right side 2 onto bottom
0 and plinth !.
Use a screwdriver to turn
locking nuts C clockwise
to lock.
Attach upright 3 and
small upright @ with 4x
confirmat screw G onto
bottom 0. Use allen key
f.
Attaching panels
Attach upright 3 and
small upright @ onto small
horizontal # with 6x
screw R.
Finished
front edge
Finished
front edge
I
AG
I
AG
C
R
R
R
R
R
R
1
2
3
3
13
12
12
11
10
G
G
G
G
AF
