Ariel JGP User Manual

FOR MODELS: JGI, JGM, JGN, JGP AND JGQ SECTION 3 - START UP
9/08 PAGE 3-7
START-UP CHECK LIST - INSTRUMENTATION
Description Date Checked Date Verified
1. Check and verify the set point for the high compressor oil
temperature shutdown at 190°F (88°C) maximum.
Commissioning Agent:
__________________
Distributor:___________
2. Check and verify proper vibration shutdown installation
and operation. Record alarm and shut down settings.
________________________________________
________________________________________
________________________________________
________________________________________
Commissioning Agent:
__________________
Distributor:___________
3. Verify operation of suction pressure, inter-stage pressure,
and discharge pressure shutdowns. Record alarm and
shutdown settings.
________________________________________
________________________________________
________________________________________
________________________________________
Commissioning Agent:
__________________
Distributor:___________
4. Verify gas discharge temperature shutdowns operation.
Record alarm and shutdown settings.
________________________________________
________________________________________
________________________________________
________________________________________
Commissioning Agent:
__________________
Distributor:___________
5. Check, verify, and record the over speed setting.
___
__________________
Commissioning Agent:
__________________
Distributor:___________
START-UP CHECK LIST - FORCE FEED LUBRICATION SYSTEM
Description Date Checked Date Verified
1. Check and verify force feed lubricator box for proper oil
level.
Commissioning Agent:
__________________
Distributor:___________
2. Prime the force feed lubrication system through the purge
port at the force feed pump discharge manifold. Check and
verify each tube connection for tightness
Commissioning Agent:
__________________
Distributor:___________
3. Check and verify operation of force feed lubrication system
no flow shutdowns.
Commissioning Agent:
__________________
Distributor:___________
4. Record color of force feed blow out discs (see Customer
Technical Bulletin CTB-137 for disc ratings).
________________
Commissioning Agent:
__________________
Distributor:___________
5. Check, verify, and record recommended lube feed rates
from lubricator data plate or “Parts Book” Cylinder Lubrica-
tion sheet.
____________________
Commissioning Agent:
__________________
Distributor:___________
