Ariens 22-Ton Log Splitter User Manual

EN - 10
1. Draw Bar
2. Engine Switch
3. Choke Control Lever
4. Fuel Shut-Off Valve
5. Safety Chains
6. Front Stand
7. Front Stand Lock Pin
8. Hydraulic cylinder
9. Control Lever
10. Splitter Wedge
11. Beam
12. Rear Stabilizer
13. Stripper Plate
14. Beam Assembly Lock
15. Hydraulic Pump
16. Hydraulic Tank
17. Hydraulic Tank Dipstick/Breather
18. Control Valve
19. Hydraulic Oil Filter
20. Recoil Starter
21. Muffler
22. Log Cradle
23. End Plate/Grip
24. Fuel Tank and Cap
25. Hitch Coupler – 2" Ball
26. Engine Oil Drain
CONTROLS AND FEATURES
Figure 4
2
1
3
6
9
10
13
11
5
7
15
19
14
17
18
16
23
4
20
21
22
8
24
25
26
12
