20 Tensor
2
Login
(Contd.)
A user has to be selected/logged in on initial switch on or after a voltage loss, even if no password was given for the
selected user.
If no password was stored for the user, the password entry is skipped and the rst menu item will be displayed.
Password entry:
• Select the appropriate gure via buttons L & R (actual gure is ashing)
• To edit the gure press the MENU button --> An underscore is shown below the gure.
• Set selected gure by using buttons L & R.
• Conrm the set gure with the MENU button.
• Navigate to the conrmation arrow after password entry and conrm with the MENU button.
No error message is shown when entering a wrong password. A correct password or the active user is marked with an
asterisk (*) behing the selected user.
Example with user "User":
Password correct/User active: > User*
Password wrong/User inactive: > User
End positions End positions
Selection and setting of the left (EL) and right (ER) end position.
Approach end positions using buttons L and R and then store them.
Procedure:
• Select the end position to be set
• Within the display "<EL>" or "<ER>" approach left resp. right end position via buttons L & R and conrm with
MENU button
• Accept (Y) or cancel (N) storing the end positions. Change between (Y)/(N) via buttons L & R, conrm selection
with MENU button.
Motor or parts can be damaged when driving against obstacles. The motor does not stop at the prior set end positions
during an end position is re-programmed. Drive the actuator slowly and carefully when setting new end positions.
Left and right end positions can be interchanged. The assignment of the turning direction of the inputs 2/3 and the
buttons LI/RE do not change.
The end positions must be 28° apart due to technical reasons. If the difference range is too small, the actuator will
prompt "Error Code 51".
