24 Tensor
2
Relay switching state
1 (switched on/active)
0 (switched off/inactive)
left
end position
right
end position
[3] Sw.pt.low
SP
Relay switching state
1 (switched on/active)
0 (switched off/inactive)
left
end position
right
end position
[4] Cam high
SP1
SP2
Relay switching state
1 (switched on/active)
0 (switched off/inactive)
left
end position
right
end position
[5] Cam low
SP1
SP2
Relay switching state
1 (switched on/active)
0 (switched off/inactive)
left
end position
right
end position
[6] Bl.det.le
Blockade at
left end position
