Aristel DV-22 - D4 Dlub（Key Station Card

System Installation Manual
Digital Key Telephone System
22
DV
4.5 D4DLUB（Key Station Card）
2
1
Figure 5: DV-22 Key Station Card Unit (D4DLUB)
1. For D4MBUB connection.
2. Quick-Connector Module for Key phone connection,（Use 2-wire T/R）, including 4
sets of 6 wires RJ-12 Connector.
NOTE：D4DLUB（Key Station Card）consists of（8 Digital Key Station Ports）
REFER TO PAGE 24 FOR CONNECTION DETAILS
