Checking slow ignition power
The soft light can be adjusted between the maximum power and
the minimum power.
The display shows the value between “100” and 0 of this interval.
Change the parameter if the outlet pressure from the gas valve
in the ignition phase (measured when the boiler is in hot water
heating operation) does not coincide with the values shown in the
Gas Regulation Table.
To check the slow ignition power, access parameter 2.2.0.
If needed, change the parameter value until suitable pressure is
achieved.
Heating ignition delay adjustment
This parameter – 2.3. 5 - can be used to manually (0) or automatically
(1) set the delay time before the subsequent reignition of the burner
after it has switched o on reaching the desired temperature.
By selecting manual, it is possible to set the delay in minutes using
the successive parameter (menu 2.3.6), to a time between 0 and 7
minutes.
Automatic selection means that the boiler will establish the delay
time based on the set-point temperature.
Gas changeover
The boiler can be converted to use either methane (natural) gas
(G20) or L.P.G. ( G31) by an Authorised Service Centre.
The operations that must be performed are the following:
1. switch o the the electrical supply to the appliance
2. turn o the gas cock
3. disconnect the electrical connections to the boiler
4. gain access to the combustion chamber, as indicated in the
paragraph “Maintenance Guide - General Access”
5. add/remove the gas diaphragm as directed in the instruction
sheet for the Kit.
6. attach the labels contained inside the Kit
7. check that all connections are gas-tight
8. start up the boiler
9. carry out combustion analysis check CO2 parameters.
Gas regualtion table Parameter
45 65 85 100
G20 G31 G20 G31 G20 G31 G20 G31
Lower wobbe index (15°C, 1013 mbar) (mJ/m3) 45,67 70,69 45,67 70,69 45,67 70,69 45,67 70,69
Slow ignition 220 53 53 53 53 55 55 54 54
Maximum heating power adjustment 231 99 99 99 99 99 99 99 99
Minimum fan speed(%) 233 11 11 12 12 9 9 11 11
Maximum central heating fan speed (%) 234 75 75 80 80 88 88 91 91
Maximum d.H.W fan speed (%) 232 75 75 80 80 88 88 91 91
Gas valve restrictor (ø) (mm) NO 6,8 NO 6,8 NO 6,0 NO 6,2
Gas ow max/min (15°C, 1013 mbar)
(Nat - m3/h) (LPG - kg/h)
max 3,8 3,2 5,3 4,5 7,3 6,3 8,1 6,9
min 1,1 1,0 1,6 1,4 1,8 1,6 2,0 1,7
Parameter
115 150
G20 G31 G20 G31
Lower wobbe index (15°C, 1013 mbar) (mJ/m3) 45,67 70,69 45,67 70,69
Slow ignition 220 47 47 54 54
Maximum heating power adjustment 231 90 90 99 99
Minimum fan speed(%) 233 14 14 12 12
Maximum central heating fan speed (%) 234 96 96 85 85
Maximum d.H.W fan speed (%) 232 96 96 85 85
Gas valve restrictor(ø) (mm) NO 8,0 NO 8,0
Gas ow max/min (15°C, 1013 mbar)
(Nat - m3/h) (LPG- kg/h)
max 10,0 8,5 12,8 10,9
min 2,5 2,1 3,2 2,7
