user’s manual
用户手册
Control panel
24/01/2011 12:25
44°C 40°C
1
2
3
6
5
4
7
12
10
11
9
8
WARNING
rst ignition and maintenance work must be performed
ed personnel only, in accordance with the instructions
provided.
Incorrect installation may harm individuals, animals or property;
the manufacturer will not be held responsible for any damage
caused as a result.
Legend:
1. Display
2. Domestic Hot Water adjustment button +/-
3. ON/OFF button
4. Pressure gauge
5. Flame detected Blue LED
5. Esc button (Back)
6. “encoder” programming knob
7. Ok button programming key
9. MODE button
(Operation mode selection summer/winter)
10. RESET button
11. Auto button (To activate Thermoregulation)
12. Heating temperature adjustument button +/-
控制面板
图例:
1. 显示屏
2. 生活热水温度调节键 +/-
3. 开／关键
4. 供暖系统水压表
5. 火焰显示蓝色 LED
6. 退出键 (返回)
7. “编码器” 旋钮
8. OK键（确认键）
9. 模式键
(选择运行模式 夏季/冬季)
10. 复位键
11. Auto 键 (激活室内温度调节规则)
12. 供暖出水温度调节键 +/-
