Ariston GENUS PREMIUM EVO HP 85

área técnica
technical area
52
2. 4. 4 Boost Time from 0 to 60
(minutes)
16
only enabled with Room Thermostat on/o and
temperature adjustment activated (parameter 421 or
521 or 621 on 01 = Basic temperature adjustment)
This parameter can be used to set the delay time before
the automatic increase in  ow temperature, in steps of
4°C (max. 12°C). If the value of this parameter remains at
00 the function is not activated.
2. 4. 5 Circulation pump MAX
speed
from 75 to 100 100
GENUS PREMIUM EVO HP 85/100/115/150
with optional pump kit - modulating
2. 4. 6 Circulation pump MIN
speed
from 40 to 100
GENUS PREMIUM EVO HP 85/100/115/150
with optional pump kit - modulating
2. 4. 7 Central Heating Pressure
detection device
0 = Temperature
Probes only
1 = Pressure switch
2 = Pressure sensor
2
ONLY FOR SERVICE - To be used only in substitution P.C.B.
2. 4. 9 External temperatura
correction
from -3 to +3 0
Only active with external sensor connected
2. 5
DOMESTIC HOT WATER
Activated with the boiler connected to a tank by an NTC sensor
2. 5. 0 COMFORT Function 0 = Disabled
1 = Time Based
(30 minute)
2 = Always active
0
This function keeps the external tank warm during the
periods in which the boiler is inactive.
When the function is enabled the text COMFORT appears
on the display.
Note: this function can be activated or deactivated by the
user as well - consult the User’s Manual.
2. 5. 1 Comfort Anti-cycling Time from 0 to 120
minutes
0
2. 5. 2 Hot water  ow delay from 5 to 200
(0.5 to 20 seconds)
5
Anti "water hammering"
2. 5. 3 D.H.W. switch logic 0 = Anti-scale
(stop at > 67°C)
1 = At 4°C over set-
point
0
2. 5. 4 Post-circulation and post-
ventilation after domestic
hot water is drawn
0 = OFF
1 = ON
1
OFF = 3 minutes post-circulation and post-ventilation
after domestic hot water draw-o if the boiler temperature
measured requires it.
ON = always on for 3 minutes post-circulation and post-
ventilation after domestic hot water draw-o .
2. 5. 5 Delay start in Central
Heating after D.H.W.
request
from 0 to 30
(minutes)
0
2. 4. 4 Tiempo Incremento
temp. Calefacción
de 0 a 60 (minutos) 16
activo sólo con T. A. on/o y Termorregulación activada
(parámetro 421/521/621 su 01 = Dispositivos On/O )
Dicho parámetro permite  jar el tiempo de espera para
el aumento automático de la temperatura de impulsión
con intervalos de 4ºC (máx. 12ºC). Si dicho parámetro
permanece con valor 00 la función no se activa.
2. 4. 5 Max PWM bomba de 75 a100
GENUS PREMIUM EVO HP 85/100/115/150
con kit bomba opcional - modulación
2. 4. 6 Mín PWM bomba de 40 a 100
GENUS PREMIUM EVO HP 85/100/115/150
con kit bomba opcional - modulación
2. 4. 7 Dispositivo Medición\rde
Presión Calef.
0 = Sólo Sondas Temp
1 = Presóstato
Mínima
2 = Detector Presión
2
RESERVADO AL SERVICIO DE ASISTENCIA TÉCNICA Sólo
en caso de sustitución de la placa electrónica
2. 4. 9 Corrección temperatura
externa
de -3 a +3 (°C)
sólo con sonda externa conectada
2. 5
CIRCUITO SANITARIO
Activado con caldera conectado con acumulador
esterno (sonda NTC)
2. 5. 0 Función Confort 0 = Deshabilitada
1 = Temporizado
(30 minutos)
2 = Siempre Activo
0
El aparato permite aumentar el confort del agua
caliente sanitaria a través de la función “CONFORT”.
Esta función mantiene la temperatura del acumulador
durante un periodo de inactividad de la caldera.
Cuando la función está activa, la pantalla indica
CONFORT Nota: Tale funzione può essere attivata o
disattivata anche premendo il tasto C
OMFORT.
2. 5. 1 Tiempo Anticiclado
Confort
de 0 a 120 (minuto)
2. 5. 2 Retraso comienzo Circ.
San.
de 5 a 200
(de 0,5 a 20 segundo)
5
2. 5. 3 Lógica Apagado
Quemador Sanitario
0 = Anticalcáreo
(>67°C)
1 =
Al Set-point + 4°C
0
2. 5. 4 Post-enfriamiento
Sanitario
0 = OFF
1 = ON (3 minutos)
0
2. 5. 5 Retraso Circuito
Sanitario-> Calefacción
de 0 a 30 (minutos) 0
menú submenú parámetro Descripción Campo de regulación Con guraciones de fábrica
menu sub-menu parameter description value default setings
