Ariston MICROCOMBI 23 MFFI - Control Panel Legend; On;Off Button and Indicator; Temperature Adjustment Controls; System Status Indicators

7
LEGEND:
A - On/Off button
B - Central heating temperature adjustment
C - Domestic hot water temperature adjustment
D - Heating system pressure gauge
E - Time clock
F - Central heating selector
G - Central heating L.E.D. (green)
H - Fume sensor L.E.D. (yellow)
I - Overheat and/or ignition failure (lockout) L.E.D. (red)
J - Ignition failure (lockout) and/or overheat reset button
K - ON/OFF L.E.D. (green)
