(*) BUS power supply overload
A BUS power supply overload error may occur due to the con-
nection of three or more devices within the installed system.
Devices which may overload the BUS network include:
- Multizone module
- Solar pump assembly
- Module for instant production of domestic hot water
To avoid overloading the BUS power supply, set microswitch
1 on one of the P.C.B.s inside the equipment connected to the
system (except the Tank) to OFF, as illustrated in the  gure.
1
ON
OFF
2
microswitch
(**) Table of inverter error codes
in case of an external unit error (HP 939 error code), read the
parameter 17.11.1 and refer to the following table to identify
the cause of the error.
EXTERNAL UNIT ERROR LIST
TDM
ERROR
DESCRIPTION
RESET
HP
POWER
OFF
SERVICE
RESET
905 HP CMP Mismatch Error x
906 HP FAN Mismatch Error x
907 HP V4W Mismatch Error x
908 HP EXV Mismatch Error x
909 HP Zero Fan Speed x
947 HP V4W Error x
912 HP V4W Error Service x
948 HP TD Error -- --
949 HP TS Error -- --
911 HP TE Error -- --
952 HP TO Error -- --
913 HP LWT Error -- --
914 HP TR Error -- --
916 HP TEO Error -- --
915 HP COMM TDM Error -- --
953
HP Compressor Heater
Mismatch
-- --
954 HP Base Panel Heater Mismatch -- --
956
HP Compressor model
mismatch
-- --
957 HP Fan model mismatch -- --
922 HP Freeze Error x
917 HP Freeze Service -- x
951 HP HIGH TD Error x
950 HP HIGH TD Service -- x
918 HP Pump Down Error -- --
919 HP HIGH SDT Error x
931 HP INVERTER Error -- --
INVERTER
ERROR
DESCRIPTION 1ph 3ph
1 Heat Sink-Overheat xx
2 Compressor Ipm Over-Current x
3 Compressor Fail To Drive x
4 Compressor Over-Current xx
5 Input Voltage Lack Of Phase x
6 Compressor Ipm Current Sampling Failure x
7 Compressor Drive Capacitors Precharge Failure x
8 Dc Bus Over-Voltage x
9 Dc Bus Under-Voltage x
10 Ac Input Under-Voltage x
11 Ac Input Over-Current x
12 Ac Input Voltage Sampling Failure x
13 Dsp&Pfc Communication Error x
14 Heat Sink Sensor Error x
15 Dsp&Mcu Communication Error x
16 Abnormal Communication With Main Board x
17 Ipm Module Over-Heat x
18 Compressor model fault xx
19 High Pressure Protection xx
21 Fan1 Fail To Drive x
27 Fan1 Over-Current x
29 Fan1 1ph Error x
35 High pressure switch protection xx
36 Ow pressure switch protection xx
37 Klixon protection xx
38 Inter-boards communication error x
39 IPM over current x
40 Fail to drive the compressor x
41 Compressor over current x
42 IPM current sampling failure x
43 Heat-sink over-heat x
44 Fail to Precharge x
45 DC bus over voltage x
46 DC bus under voltage x
47 AC input under-voltage x
48 AC input over-current x
49 compressor emergency stop x
50 AC input voltage sampling fault x
51 Heat-sink sensor error x
52 DSP & MCU communication error x
53
Abnormal communication with IDU control
board
x
