Ariston PRO1 - Installation scheme

MOD. A B C D
50 V 543 163 480 165
80 V 748 163 480 165
100 V 900 163 480 165
90°
S12
Modelli verticali
Vertical models
MOD. A (mm) B (mm)
50 V 573 193
80 V 778 193
100 V 918 181
FLEX 80 V 778 295
FLEX 100 V 918 283
Min. 3 - Max 8 mm
Схема установки
Installation scheme
450
57
