Ariston Sensys Net - Page 33

GB / 33
134 mm 16 mm
96 mm
120 mm 23,3 mm
80 mm
WEBBUS A.P.
Sensys
Gateway
Legend:
1. BridgeNet Bus LED
2. Internet Connection LED
3. WiFi configuration butto
Legend:
1. back button (previous
display)
2. knob
3. OK button (to confirm
operation or access main
menu)
4. DISPLAY
3
2
1
4
1
2
3
