38 /GB
Type 3
Activation of RC on a system with maximum 3 plumbing zones controlled by 1 zone
BridgeNet BUS devices, 2 zones ON/OFF
System where there is an Ariston multi-zone plumbing module to which BridgeNet Bus
zone management accessories are connected such as an Ariston Sensys and/or Ariston
ON/ OFF Thermostat.
Actions required (Fig. 6):
- Install the gateway, connecting it to the heating system via the BridgeNet BUS
connection.
- Activation of the RC of 1 zone with Sensys, and ON/OFF functionality in other zones
(refer to table)
BUS
BUS
BUS
BUS
Fig. 5 Fig. 6
SENSYS
SENSYS
THERMOSTATS
THERMOSTATS
PLUMBING
MODULE
PLUMBING
MODULE
GATEWAY
(Fig. 5)
