GB / 37
Type 2
Activation of RC on a system with maximum 3 plumbing zones controlled by
BridgeNet BUS devices
System where there is an Ariston multi-zone plumbing module to which BridgeNet Bus
zone management accessories are connected such as an Ariston Sensys and/or Ariston
Room Sensor.
Actions required (Fig. 4):
- Remove all Ariston Room Sensor accessories or thermostats in the system and
replace them with Ariston Sensys
- Install the gateway, connecting it to the heating system via the BridgeNet BUS
connection.
BUS
BUS
BUS
BUS
Fig. 3
Fig. 4
SENSYS
SENSYS
THERMOSTATS
PLUMBING
MODULE
PLUMBING
MODULE
GATEWAY
(Fig. 3)
