Ariston Zone Manager Kit User Manual

13
preparing the boiler for operation
EN
Congurations for zone-based temperature control
Zone 1 Zone 2 Zone 3
System interface
The system interface is
connected to the Zone
Manager's BridgeNet® BUS.
Assign conguration code
“1” to parameter 030 of the
system interface.
Room sensor
The room sensor is connected
to the Zone Manager's
BridgeNet® BUS.
Refer to the room sensor
manual for instructions on
assigning it to Zone 1.
Timer-controlled thermostat
The timer-controlled
thermostat is connected to
terminal block “TA1” of the
Zone Manager.
System interface
The system interface is
connected to the Zone
Manager's BridgeNet® BUS.
Assign conguration code
“2” to parameter 030 of the
system interface.
Room sensor
The room sensor is connected
to the Zone Manager's
BridgeNet® BUS.
Refer to the room sensor
manual for instructions on
assigning it to Zone 2.
Timer-controlled thermostat
The timer-controlled
thermostat is connected to
terminal block “TA2” of the
Zone Manager.
System interface
The system interface is
connected to the Zone
Manager's BridgeNet® BUS.
Assign conguration code “3”
to parameter 030 of the system
interface.
Room sensor
The room sensor is connected
to the Zone Manager's
BridgeNet® BUS.
Refer to the room sensor
manual for instructions on
assigning it to Zone 3.
Timer-controlled thermostat
The timer-controlled
thermostat is connected to
terminal block “TA3” of the
zone manager.
LED signal
GREEN LED (left)
Indicator o Power supply OFF
Indicator lit Power supply ON
Indicator ashing Power supply ON, manual mode operation
GREEN LED (centre)
Indicator o BridgeNet® BUS communications absent
Indicator lit BridgeNet® BUS communications present
Indicator ashing Initialisation of BridgeNet® BUS communications
RED LED (right)
Indicator o No operation errors
Indicator lit Presence of one or more operation errors
