Aritech IU2080NC User Manual

P/N 10-5106-501-80NC-04 • ISS 01OCT21 3 / 24
Maintenance
Basic maintenance consists of a yearly inspection. Activate the
notification output at least once a year to ensure correct
operation. Do not modify internal wiring or circuitry.
Specifications
Loop input
Operating voltage
17 to 28 VDC
Current consumption
Standby
Activated
< 250 µA (< 200 µA typical)
< 3.5 mA
External power supply
Operating voltage
20.1 to 28 VDC
Low voltage detection
< 19.7 VDC
Current rating
at 20°C
at 55°C
Minimum load
3.00 A
2.04 A
100 mA
Notification
circuit
Circuit impedance at 24 V
Short circuit
Standby
Open circuit
< 4.5 kΩ
5.5 to 16 kΩ
> 20 kΩ
Supervisory voltage
1.7 VDC, inverted at 10KΩ
End
-of-line resistor 10 kΩ, 5%, 1/4W
Current consumption
Standby
Activated [1]
< 11 mA at 24 VDC
< 12 mA at 28 VDC
< 69 mA at 24 VDC
< 70 mA at 28 VDC
Mechanical and environmental
IP rating
IP40
Operating environment
Operating temperature
Storage temperature
Relative humidity
−10 to +55°C
−20 to +60ºC
10 to 95% noncondensing
Weight
325 g
Dimensions
175 × 124 × 51 mm
[1] Excluding output circuit load from auxiliary power supply
Regulatory information
This section provides a summary on the declared performance
according to the Construction Products Regulation
(EU) 305/2011 and Delegated Regulations (EU) 157/2014 and
(EU) 574/2014.
For detailed information, see the product Declaration of
Performance (available at firesecurityproducts.com
).
EU compliance
Certification body
0370
Declaration of
Performance number
10-5106-360-2001
Year of first CE marking
18
Product identification
IU2080NC
Intended use
See the product Declaration of
Performance
Declared performance
See the product Declaration of
Performance
Manufacturer
Carrier Safety System (Hebei) Co. Ltd.,
80 Changjiang East Road, QETDZ,
Qinhuangdao 066004, Hebei, China.
Authorized EU manufacturing
representative:
Carrier Fire & Security B.V.,
Kelvinstraat 7, 6003 DH Weert,
Netherlands.
2012/19/EU (WEEE Directive): Products
marked with this symbol cannot be
disposed of as unsorted municipal waste
in the European Union. For proper
recycling, return this product to your local
supplier upon the purchase of equivalent
new equipment, or dispose of it at
designated collection points. For more
information see:
recyclethis.info.
Contact information and product
documentation
For contact information or to download the latest product
documentation, visit firesecurityproducts.com.
Product warnings and disclaimers
THESE PRODUCTS ARE INTENDED FOR SALE TO AND
INSTALLATION BY QUALIFIED PROFESSIONALS.
CARRIER FIRE & SECURITY B.V. CANNOT PROVIDE ANY
ASSURANCE THAT ANY PERSON OR ENTITY BUYING ITS
PRODUCTS, INCLUDING ANY “AUTHORIZED DEALER” OR
“AUTHORIZED RESELLER”, IS PROPERLY TRAINED OR
EXPERIENCED TO CORRECTLY INSTALL FIRE AND
SECURITY RELATED PRODUCTS.
For more information on warranty disclaimers
and product safety information, please check
https:
//firesecurityproducts.com/policy/product-
warning/
or scan the QR code:
CS: Instalační návod
Popis
Tento dokument obsahuje informace o instalaci řídicího
modulu sirén IU2080NC. Modul nabízí monitorovaný výstup
pro zařízení, která poskytují zvuková a vizuální oznámení, a je
navržen pro použití s adresovatelnými požárními systémy
FP1200C-2000C a 2X Series.
Modul je napájen přídavným zdrojem 24 V a dokáže spínat
výstupní proud až 2,04 A. U externího napájecího zdroje se
monitoruje nízké napětí a u externího poruchového relé
rozpojený obvod.
Upozornění: Je nutno použít externí napájecí zdroj
odpovídající normě EN 54-4. Z bezpečnostních důvodů
napájejte vždy jen jeden modul IU2080NC z jediného
napájecího zdroje.
Modul s nainstalovaným zakončovacím odporem zjišťuje
v oznamovacím obvodu zkrat a rozpojený obvod.

Aritech IU2080NC Specifications

General

Brand	Aritech
Model	IU2080NC
Category	Controller
Language	English
