ARL-300 User Manual V2.51
17. ARL-300 TERMINALS & PLUGS
17.1. Common Terminals on ARL-300 Controller
L1,L2,L3
Main Phase
N
Neutral
1
Car Supply Output (220Vac)
2
Car Lamp Output (220Vac)
LO
Relay Output of Retiring Cam (Common Contact)
LA
Relay Output of Retiring Cam (Normally Open Contact )
K3
Door Close Signal Output
K5
Door Open Signal Output
K15
Door Open/Close Signal Common
10A
Safety Circuit Supply Ground Input
120
Stop Circuit Monitoring Input
Max. 230Vac
130
Landing Door Contacts Monitoring Input
140A
Landing Door Lock Contacts Monitoring Input
140B
Landing Door Lock Contacts Monitoring Input
(During evacuation operation for rope lifts with AKUS-SD or hydraulic systems)
Max. 28Vdc
10B
Common of Main Contactors Output
SF1
Door Bridging Relay Contact Common (120 circuit)
Only for VVVF and Hydraulic systems
for door pre-opening and relevelling.
SF2
Door Bridging Relay Contact Output (140 circuit)
ML1 (M1)
Door Zone Magnetic Switch-1 Input
These connections depend on the drive
type of the elevator.
ML2
Door Zone Magnetic Switch-2 Input
141
Down Stop & Deceleration Magnetic Switch Input
142
Up Stop & Deceleration Magnetic Switch Input
PT0
Programmable Output (M0: Gray/Binary Code Output)
The functions of programmable
outputs are assigned from the
menu.
PT1
Programmable Output (M1: Gray/Binary Code Output)
PT2
Programmable Output (M2: Gray/Binary Code Output)
PT3
Programmable Output (M3: Gray/Binary Code Output)
KRC
Contactors Feed-back Input
S2A-S2B
Group Operation Communication Terminals
S1A-S1B
Car Communication Terminals (for comm. with FX-SERI boards)
1000
Signal Circuit Ground
100
Signal Circuit Supply (+24Vdc)
PTC
Motor Thermistor & Panel Thermostat
Oil Thermostat Input (Hydraulic) & Brake Resistor Thermostat (VVVF)
K19 Door Close Limit Switch Input
These inputs must be bridged to terminal 100 when door limit switches are
not checked by ARL-300 controller (excluding 1-phase and 3-phase
automatic lift doors)
K16 Door Open Limit Switch Input
PR
Programmable Relay Common Input
The function of this output is assigned from the menu.
PRA
Programmable Relay Output
XK1
To XK1 plug on KBK4 Connection Board with 14-wire flat cable
XK2
To XK2 plug on KBK2 Connection Board with 20-wire flat cable
XK3
To XK3 plug on KBK2 Connection Board with 20-wire flat cable
17.2. Relay Output Terminals According to Drive Type
Relay Outputs for Two Speed Systems:
V11
KU1, KU2, KH Contactors Supply Common
VA
Up Direction Contactor (KU2) Output
VB, VC
High Speed Contactor (KH) Output
VD
Down Direction Contactor (KU1) Output
RU
Low Speed Contactor (KF) Output
11
Low Speed Contactor (KF) Supply Common
