Arlec PEH002 User Manual

7
QUICK START GUIDE
FUNCTION STEPS (Refer to Fig.3) DIGITAL DISPLAY (Refer to
Fig.4)
TO TURN ON Plug the heater into the
mains socket and operate
the ON/OFF switch “7” to I
and unscrew plastic cover.
The timer symbol and
day/time display will
flash when used for the
first time, or after being
turned off for an extended
period. The time must be
set for the heater to work.
SETTING THE TIMER
Day Press the TIMER button.
Use the DOWN “10” and
UP “11” buttons to set day.
The day will flash.
The timer symbol will
be shown.
Hour Press the TIMER button.
Use the DOWN “10” and
UP “11” buttons to set day.
The hour number will
flash.
Minutes Press the TIMER button.
Use the DOWN “10” and
UP “11” buttons to set
minutes.
The minute number will
flash.
Clock Press the TIMER button to
exit setting.
Selecting a pre set
program
Press the Program
Selection P button “5”,
refer to Pre Set Programs.
The display will now show
the day, the last selected
Pre selected program
(which will flash), the
temperature and program
sequence.
Use the DOWN and UP
buttons to select desired
program.
Press the Program
selection P button “5”
again to terminate the
setting.
Depending on the time
and program set, one
of the following will
illuminate
Comfort Period = Orange
& Red
Economy Period = Orange
Standby = Green
