ARM MPS3 User Manual

Table A-12 Connector J28 (Pmod0/1 interface) signal list
Pin Signal Pin Signal
1 SH0_5V_IO3 7 SH0_5V_IO4
2 SH0_5V_IO1 8 SH0_5V_IO2
3 SH0_5V_IO0 9 SH0_5V_IO15
4 SH0_5V_IO9 10 SH0_5V_IO14
5 GND 11 GND
6 SHO_REF 12 SHO_REF
The following table shows the pin mapping for the Pmod2/3 interface connector, J34.
Table A-13 Connectors J34 (Pmod2/3 interface) signal list
Pin Signal Pin Signal
1 SH0_5V_IO10 7 SH1_5V_IO5
2 SH0_5V_IO11 8 SH1_5V_IO6
3 SH0_5V_IO12 9 SH1_5V_IO7
4 SH0_5V_IO13 10 SH1_5V_IO8
5 GND 11 GND
6 SH1_REF 12 SH1_REF
The following table shows the pin mapping for the Pmod2/3 interface connector, J38.
Table A-14 Connectors J38 (Pmod2/3 interface) signal list
Pin Signal Pin Signal
1 SH0_5V_IO3 7 SH1_5V_IO4
2 SH0_5V_IO9 8 SH1_5V_IO2
3 SH0_5V_IO0 9 SH1_5V_IO15
4 SH0_5V_IO1 10 SH1_5V_IO14
5 GND 11 GND
6 SH1_REF 12 SH1_REF
Related information
2.16 Arduino Shield and Pmod interfaces on page 2-43
1.3 Location of components on the MPS3 board on page 1-15
A Signal descriptions
A.3 Peripheral Module (Pmod) connectors
