Link Removal
To remove a link from a pin link bracelet, you will need the bracelet holder, pin pusher,
and chain nose pliers (see pin link diagram).
1. Open the clasp on the bracelet.
2. Look on the inside of the bracelet and locate the arrows near the clasp (see diagram).
3. Place the band into the appropriate size slot of the bracelet holder with the arrows
pointing down (see diagram).
4. Center the desired pin to be removed over one of the holes in the bottom of the
bracelet holder.
5. With the pin pusher, push the pin, as far as possible, through the link.
6. Remove the watch from the bracelet holder and simply finish pulling out the pin with
the chain nose pliers.
NOTE:
Two pins hold each link in place and must be taken out before a link can be
removed.
Please note that the pins are partially split down the center.
PIN LINK DIAGRAM
BRACELET HOLDER
CHAIN NOSE PLIERS
PIN PUSHER
ARROWS
