INSTALLING & REMOVING THE HOSE
INSTALLING & REMOVING ACCESSORIES
1. Pull the work end of the hose out of the hose storage. (Fig. 1)
2. The other end of the hose is already connected to the vacuum port; make sure it is secure.
3. This wet/dry vacuum has blowing capabilities. To use as a blower, connect the larger end of the
hose to the blower port. (Fig. 2)
Choose the desired accessories and push onto the smaller end of the hose. (Fig. 3.1)
Note: This wet/dry vac comes with an adaptable utility nozzle. This accessory can be used as a
wet nozzle, a brush, or a pet hair rake. To use the slide-on adapters follow these instructions:
1. Choose the brush or the pet hair rake adapter.
2. With the nozzle facing up, slide the adapter onto the utility/car nozzle until it clicks into place. (Fig.
3.2)
3. To remove, press the tab on the right side of the adapter and slide it off the utility/car nozzle. (Fig.
3.3)
1 2
3.1 3.2 3.3
