6
GENERAL ASSEMBLY INSTRUCTIONS
UNPACKING YOUR WET/DRY VACUUM & GENERAL ASSEMBLY
1. Verify that the power cord is disconnected from the outlet. (g. 1)
2. Undo the latches. (g. 2)
3. Lift the power head off the container. (g. 3)
4. Remove the contents from inside the container, make sure you have all contents as listed on page 5. (g. 4)
5. Turn the container upside down and insert the four caster feet into the slots on the container and tighten with supplied
screws. Verify that the casters are mounted correctly. Do not over-tighten screw. (g. 5)
6. Your vacuum comes ready for dry vacuum cleaning. If cartridge lter is not installed refer to page 10 for lter
installation. (g. 6 & 7)
7. For wet vacuum cleaning, install the supplied foam lter. (g. 8) See page 11 for lter installation.
8. Place the power head back on the container, aligning the top section with the latches, and snap into place. Keep in
mind to position the power head so that the blower port is towards the rear. (g. 9)
9. Insert the locking end of the hose into the port of the container and lock in to place. (g. 10)
10. Choose the desired wands or accessories and push onto the hose. (g. 11)
POLARIZED PLUG
To reduce the risk of electrical shock, this appliance has a polarized plug (one with the blade wider than the other). This
plug will t in a polarized outlet only one way. If the plug does not t fully in the outlet, reverse the plug. If it still does not
t, contact a qualied electrician to install the proper outlet. Do not change the plug in any way. Double insulation
eliminates the need for the three wire grounded power cord and grounded power supply system.
9
10
2
2
1
5
3
4
8
11
6
7
WARNING:
DO NOT PLUG IN POWER CORD TO POWER OUTLET, MAKE SURE PLUG IS DISCONNECTED
BEFORE ASSEMBLING THE WET/DRY VACUUM.
A Philips head screwdriver is required.
