Arnott C-2242 - Remove the Break Caliper Retaining Clip. (Figure

5
REV 3 12/04/2014
C-2242
C-2242
ARNOTT COIL SPRING CONVERSION KIT
FOR
1999-2006
MERCEDES-BENZ S-CLASS (W220 CHASSIS)
3. DISCONNECT THE AIRLINE AND REMOVE THE 3 MOUNTING NUTS FROM THE TOP OF THE AIR SHOCK. (FIGURE 20-2)
4. REMOVE RUBBER BOOT AND DISCONNECT ELECTRICAL CONNECTOR LEADING TO THE SHOCK DAMPER
SOLENOID. (FIGURE 20-3).
5. REMOVE THE BREAK CALIPER RETAINING CLIP. (FIGURE 20-4)
FIGURE 20-2
FIGURE 20-4
FIGURE 20-3
