5
REV 2 11/18/2013
C-2278
C-2278
ARNOTT COIL SPRING CONVERSION KIT
FOR 2002-2009
MERCEDES-BENZ E-CLASS
FIGURE 10-8
FIGURE 10-9
11. UNPLUG THE ELECTRICAL CONNECTOR. (FIGURE 10-9)
10. REMOVE THE AIR LINE. (FIGURE 10-8)
12. REMOVE THE THREE TOP MOUNTING BOLTS. (FIGURE 10-10)
FIGURE 10-10
