Arnott C-2278 - Front Air Strut Installation Procedure

7
REV 2 11/18/2013
C-2278
C-2278
ARNOTT COIL SPRING CONVERSION KIT
FOR 2002-2009
MERCEDES-BENZ E-CLASS
FIGURE 20-1
FIGURE 20-2
2. POSITION THE BOTTOM MOUNT ONTO THE CONTROL ARM. (FIGURE 20-2)
FRONT AIR STRUT INSTALLATION
1. INSTALL THE STRUT INTO THE UPPER MOUNT CAVITY. (FIGURE 20-1)
3. INSTALL THE BOTTOM MOUNT NUT AND BOLT. (FIGURE 20-3)
FIGURE 20-3
Tighten all nuts and bolts to manufacturer's specications during the installation process.
