Arrakis Systems ARC-10UP - Electronic Specifications

SPECIFICATIONS
Stereo Line Input
Freq Response- +(-).5dB 20-20kHz
S/N- -82dB typ, +8dBu in, +8 dBu out
THD- .01% typ, +8dBu in, +8 dBu out
CMRR- -75dB typ 1kHz
Max Input- +23dBu, balanced
+17dBu unbalanced
Mono Mic Input
Freq Response- +(-).5dB 20-20kHz
EIN- -115dBu typ, -50dBu in, +8 dBu out
THD- .05% typ , -50dBu in, +8 dBu out
CMRR- -60dB typ 1kHz
Impedances
Mic Input- > 2000 ohms
Line Input- > 10000 ohms
Outputs- < 100 ohms
System
Max Output- +23dBu balanced
+17dBu unbalanced
Stereo Separation- -75dB typ 1KHz
Pgm to Aud XTalk- -80dB typ 1KHz
-70dB typ 20kHz
Cue to Pgm XTalk- -90dB typ 1KHz
-75dB typ 20kHz
On Air Light Logic: open collector transister
to ground, 10mA max
P R O D U C T D E S C R I P T I O N
Electronic specifications
2.7
POWER SUPPLY
110vac - 220 VAC,
50-60 hz, autosensing
Certified: UL, CE, CS, CB
External inline module
3"W x 5 3/4"L x 1 3/4"D
PHYSICAL DIMENSIONS
Depth - 15",
Height - 6"
Width- 24"
