X T R E M E F O R T H E A R C - 1 0
5.14
Xtreme uses the standard Digilink file export format as shown below.
FIELD COL SIZE TYPE DESCRIPTION
Record type 1 2 numeric 02-traffic, 03-music
Cart # 4 8 alpha-numeric
Title 13 24 alpha-numeric
Runtime 38 4 numeric 0-3600 seconds
na 43 1 na
Air month 45 2 numeric 1-12
Air day 48 2 numeric 1-31
Air year 51 2 numeric 0-99
Air hour 54 2 numeric 0-23
Air minute 57 2 numeric 0-59
Air second 60 2 numeric 0-59
na 63 2 na
na 66 2 na
na 69 2 na
Cross in time 72 2 numeric 0-9
Cross out time 75 2 numeric 0-9
na 78 1 na
na 80 8 na
na 89 8 na
na 98 20 na
na 119 2 na
na 122 2 na
na 125 2 na
CRLF 127 1 CRLF
Notes:
a) Each record is 128 bytes long beginning with column 1.
b) Records must be in sequential order by date and time
c) Time is 24 hour format
d) All fields are ASCII characters
e) Unused fields and columns must be blank
f) Alpha-numeric fields must be left justified
The Exported Play Log Text Format
