Array electronic AF-10MR-A User Manual

C
hapter
I I
ntroduction to
FAB
9
AF-20MT-E DC12-24V
12 points DC digital in-
put
8 points transistor output
(equivalent NPN)
10
AF-20MR-D DC 12-24V
12 points DC(with ana-
log) digital input
8 points relay output
11
AF-20MT-D DC12-24V
12 points DC (with ana-
log) input
8 points transistor output
(equivalent NPN)
12
AF-20MT-GD DC12-24V
12 points DC (with ana-
log) input
8
(equivalent PNP)
13
AF-LCD-L
The removable LCD panel for programming(The wide-range tempera-
ture type -20 C~70 C)
14
AF-LCD-B
The removable LCD panel for programming(The wide-range tempera-
ture type -20 C~70 C and back light display)
15
AF-CAP A general cover instead of AF-LCD panel
16
AF-C232 A cable connecting FAB and PC (prole plug type)
17
AF-D232 A cable connecting FAB and PC (frontispiece plug type)
18
AF-C485
A cable connecting FAB and RS485 bus, monitoring via net (prole plug
type)
19
AF-D485
A cable connecting FAB and RS485 bus, monitoring via net (frontispiece
plug type)
20
AF-P485 The interface between PC and RS485 monitoring via net
21
AF-MUL Phone voice block for recording &broadcasting (AC power)
22
AF-MUL-D Phone voice block for recording &broadcasting (DC power)
23
AF-COPY Copy Module
24
AF-CMP The cable connecting PC to the voice block port “To PC”
25
AF(SR)-USB USB/RS232 converter (DIN installation)
26
AF-S485 RS232/RS485 converter (DIN installation)
27
AF-DUSB A cable connecting FAB to PC USB port (frontispiece plug type)
28
CD-ROM FAB software QUICK II and SCADA
29
AF-AUD The wire between PC sound card and AF-MUL/AF-MUL-D
3
points transistor output
