Contents
Warnings - PLEASE READ
I t i s t h e p a r e n t s ’ o r g u a r d i a n s ’
responsibility to ensure minors receive
appropriate guidance when maintaining or tuning this
model. At points this guide may recommend using
tools that are sharp and adhesives. Any such tools,
adhesives or other chemicals are for adult use only. Do
NOT allow minors to use age restricted products such
as solvents or adhesives.
Always ensure that nuts and bolts are properly
fastened and that components are free of damage or
wear before use. Failure to properly maintain your
model may lead to loss of performance, injury to
yourself or others and/or damage to property or your
model.
Upgraded parts may put extra strain on standard
parts. Always ensure that the tyres, wheels and
transmission can handle any increase in power/speed.
Further advice for safely running your model can be
found in the warranty document in your welcome pack
at ARRMA-RC.com/GO
Page
CHASSIS OVERVIEW
3
RECOMMENDED TOOLS
4
BASIC TROUBLE SHOOTING
4
Trouble Shooting Matrix
4
MAINTENANCE
5
Maintenance Schedule
5
Chassis Maintenance
6
Wheel and Tyre Maintenance
6
Slipper Clutch Adjustment
7
Spur/Pinion Mesh
7
Slipper Pad Replacement
8
Driveshaft Maintenance
9
Rear Axle Maintenance
9
Wheel Bearing Replacement
10
FACTORY SETTINGS
11
CHASSIS TUNING
13
Ride Height
13
Camber-Link Length
13
Steering Arm Length
13
Camber-Link Position
13
Shock Position
13
Shock Removal
14
Springs
14
Shock Oil
14
DRIVETRAIN TUNING
15
Gear Chart
15
Spur/Pinion Removal
15
Motor Removal
16
Differential Tuning
16
Differential Removal
17
RADIO-GEAR MAINTENANCE
19
Receiver Access
19
STEERING MAINTENANCE
19
Steering Access
19
Servo Removal
20
Support Info
At ARRMA we want you to love running your kit
and make owning a high performance RC car as simple
as possible. If you have any questions about running,
maintaining, tuning or repairing your ARRMA product,
there are three options for you to get help and advice.
Visit ARRMA-RC.com for support, parts and upgrades
for your kit. ‘GO FOR IT’ is the worldwide owner’s forum
for ARRMA. Here you will find other ARRMA owners,
get help and advice on how to get the best from your
ARRMA product. If you can’t find what you’re looking for,
you can email us at support@ARRMA-RC.com 24hrs a
day and we will do our best to help you with your query.
