Arrow ET501 - Definition of Symbols Used on Tool; Functional Description

4
BACK TO
INDEX
V …………………………… Volts
A …………………………… Amperes
Hz……………………………. Hertz
……………………………. Alternating Current
……………………………. Alert
……………………………. Wear Eye Protection
……………………………. Wear Ear Protection
DEFINITION OF SYMBOLS USED ON TOOL
FUNCTIONAL DESCRIPTION
~
6
3
5
2
4
ET501
™
for 120V
ET501
™
for 220-240V
& 220-240V(UK)
LISTED
E322184
Depth of Drive Control
Trigger
Power Cord
On/Off Switch
Staple Pusher Assembly
Contact Safety
Staple Remaining Window
1
2
3
4
5
6
7
1
7
