Step 2: Cabinet Shell - Assembly
D
G
D
I
N
Slide Cam Bolts on Panel D into Cam Locks
on Panels I and N shown.
Tighten the Cam Locks by turning 180°
clockwise.
Lay Panel D on the floor as shown, and slide the Cam Bolts
on Panel D into Cam Locks on Panel G as shown.
Tighten the Cam Locks by turning 180° clockwise.
180°
Remember to tighten the Cam Locks!
