Assembly InstructionsHarriet
15
Step 5: Top Panel
Long Cam Bolts x5
Attach Cam Bolts to Panel A as shown.
NOTE: Left and Right Leaves
(Panels B and C) come
pre-attached.
Carefully lower Panel A, inserting Cam Bolts
into Cam Locks on Panels D, F, and E.
Tighten the Cam Locks by turning 180°
clockwise.
180°
Remember to tighten the Cam Locks!
IMPORTANT NOTE: to avoid damage to
your cabinet, DO NOT extend leaves with-
out proper leaf support!
