42
Assemblies from Step 16:
• Right Door Assembly (1)
• Left Door Assembly (1)
(QTY: 8)
Closed Position
Half-Open Position
INSIDE BUILDING
Front Floor Frame
Door
Door Slide
Door Track
Gable
From inside the building, place the
bottom of the Door into the Front
Floor Frame track at about the half-
open position.
1
Rotate the Door forward until it is
vertical and align the Door Slides
with the Door.
2
Insert two (2) Black Screws into each
Door Slide as shown below. Repeat
steps for second door.
3
If Doors do not align, raise or lower one side of the Door by placing
the Door screws through a different set of holes in the Door Slide.
Door Adjustment
You will need for this page:
Step 17: Door Install
42A
To Next Page
