Arrow LW108 - Hardware List

7
HARDWARE LIST...
Key Part Part Qty.
No. No. Description List
5
6
10
11
1
2
3
4
8
9
13
14
7
12
Hardware Views by Key No.
11/32 Hex.
#2 Phillips #2 Phillips
07A
1 65103 Hex Nut (#8-32) 169
2 65900A Black Screw (#10B x 1/2) (13 mm) 8
3 65923 Bolt (#8-32 x 3/8) (10 mm) 169
4 65004 Screw (#8AB x 5/16) (8 mm) 338
5 66045 Door Handle 2
6 66646 Washer Sheet 10
7 65109 Acorn Nut 4
8 67468 Peak Cap 2
9 66769 Door Slide 4
10 66382 Lower Door Guide 4
11 66183L Left Roof Trim Cap 2
12 66183R Right Roof Trim Cap 2
13 67545 Weather Stripping 1
14 6228 Track Support 2
#2 Phillips
5/16 Hex.
The fasteners used in each step are shown
actual size at the top of each page. If you
are unsure which fastener to use, hold it up
to the picture and use the one that matches.
QTY 18
