6300 Series ComboSource User’s Manual · Page 19
Menu
Description
Factory
Default
Tol Time
Tolerance time is the amount of time, in seconds,
that the actual temperature must be within the set
point temperature +/- the Tol Temp value for the
unit to be considered in tolerance.
5 seconds
Tol Temp
Tolerance temperature is a temperature band (in
°C) around the set point temperature. When the
actual temperature is within this band for longer
than the Tol Time setting, then the unit is
considered to be in tolerance.
0.1°C
H/C Mode
This selects the heating and/or cooling mode of
the ComboSource. See the section below titled
“Resistive Heaters and Heat/Cool Only Modes” for
more information.
Heat/Cool
Ext Fan
This selects the voltage for the auxiliary fan power
supply. See the section below titled “External Fan
Control” for more information.
Off
Ext Fan Pwr
When Ext Fan is set to Custom, this sets the
specific fan voltage from 4.0 to 12.0 volts.
See the
External Fan Control section below for more
information.
12.0
Ext Fan
Mode
Controls when the fan operates. See the
External Fan Control section below for more
information.
Auto
Ext Fan Off
When Ext Fan Mode is set to Delay, this setting
defines the number of minutes to delay turning off
the fan after the TEC output has been turned off.
See the External Fan Control section below
for more information.
5 minutes
Cable R
The resistance of the cable and connectors, in
ohms. This setting allows for accurate voltage
measurement at the TEC by removing the voltage
loss of the cable.
0.0080Ω
TEC Menu » Sensor Coeffs
ThermA The A term in the Steinhart-Hart equation.
1.12924E-03
ThermB The B term in the Steinhart-Hart equation.
2.34108E-04
ThermC The C term in the Steinhart-Hart equation.
0.87755E-07
RTD A The A term in the RTD equation.
3.98480E-03
RTD B The B term in the RTD equation.
-0.58700E-06
