Arroyo Instruments ComboSource 6300 Series - Error Messages

6300 Series ComboSource User’s Manual · Page 55
Description TEC & General Specifications
Accuracy (±[% read+Ω])
0.03 + 0.1
LIMITS
CURRENT
Resolution (mA) 10
Accuracy (m
A
) 40
GENERAL
Display Type 2x20 VFD
Laser Connector DB-9, female
TEC Connector DB-15, female
Fan Supply 4 – 12V, 350mA ma
x
Computer Interface USB 2.0 Full Speed (Type B), RS-232 (DB-9, male)
Power (50/60 Hz) 100V / 120V / 230V, 150
W
Size (H x W x D) [inches (mm)] 3.47 (89) x 8.5 (215) x 12 (305)
Operating Temperature +10°C to +40°C
Storage Temperature -20°C to +60°C
Error Messages
Error
Code
Description Cause
E-100 General Error The error code is non-specific, and is generally
used when no other error code is suitable.
E-102 Message too long The message is too long to process (USB/Serial
only).
E-123 Path not found The message used an invalid path command
(USB/Serial only).
E-124 Data mismatch The message contained data that did not match
the expected format (USB/Serial only).
E-201 Data out of range The message attempted to set a value that was
outside the allowable range (USB/Serial only).
E-202 Invalid data type When trying to parse the message, the data was
in an invalid format (USB/Serial only).
E-204 Suffix not valid An invalid number base suffix (radix) was
encountered when parsing a number (USB/Serial
only).
E-402 Sensor open, output
turned off
A sensor open circuit was detected and the
output was turned off.
E-403 Module open, output
turned off
A Peltier module open circuit was detected and
the output was turned off.
E-404 I limit, output turned off A current limit was detected and the output was
turned off.
E-405 V limit, output turned
off
A voltage limit was detected and the output was
turned off.
E-406 Thermistor resistance
limit, output turned off
The thermistor resistance limit (high or low) was
exceeded and the output was turned off.
E-407 Temperature limit,
output turned off
The temperature limit (high or low) was exceeded
and the output was turned off.
E-409 Sensor changed,
output turned off
The sensor type was changed, causing the
output to be turned off.
