Page 56 · 6300 Series ComboSource User’s Manual
E-410 Temperature was out
of tolerance, output
turned off
The temperature went out of tolerance and the
output was turned off.
E-415 Sensor short, output
turned off
A sensor short circuit was detected and the
output was turned off.
E-416 Cal failed An error occurred during calibration that caused
the calibration to fail. The unit is no longer in
calibration mode.
E-419 TEC not stable The TEC is considered stable if the temperature
has changed less than 0.02°C for more than 20
seconds.
E-433 Not a TEC The TEC:CHAN command attempted to select a
non-TEC channel
E-434 Ite limit exceeds cable
rating
The cable plugged into the unit is not rated to
carry the current as set by the current limit. Use a
1262 cable, 1263 cable, or custom cable with ID
pin connected to analog ground, or reduce the
current limit below 5A.
E-435 Mode Change A mode change occurred when the output was
on, forcing the output off.
E-436 AutoTune failed The AutoTune process failed. See the “Using the
AutoTune Function” for more information.
E-437 AutoTune in T mode
only
The AutoTune process is only available in T
(temperature) mode. In R mode, the PID
parameters must be determined manually.
E-501 Interlock shutdown
output
The interlock input (pins 1 and 2 of the output
connector) were not shorted when the output was
on.
E-504 Laser current limit
disabled output.
The laser output was turned off because a current
limit was detected and the corresponding bit in
the OUTOFF register was set.
E-505 Laser voltage limit
disabled output
The laser voltage exceeded the voltage limit and
the output was turned off.
E-506 Laser photodiode
current limit disabled
output
The laser output was turned off because a
photodiode current limit was detected and the
corresponding bit in the OUTOFF register was
set.
E-507 Laser photodiode
power limit disabled
output
The laser output was turned off because a
photodiode power limit was detected and the
corresponding bit in the OUTOFF register was
set.
E-508 TEC off disabled
output
The laser output was turned off because the TEC
was off and the corresponding bit in the OUTOFF
register was set.
E-509 Laser short circuit
disabled output
The laser output was turned off because a short
condition was detected and the corresponding bit
in the OUTOFF register was set.
E-510 Laser out of tolerance
disabled output
The laser output was turned off because an out-
of-tolerance condition was detected and the
corresponding bit in the OUTOFF register was
set.
E-511 Laser control error A hardware control error was detected which
