Page 54 · 6300 Series ComboSource User’s Manual
Description TEC & General Specifications
TEC
SETPOINT
TEMPERATURE
Range (ºC)
1
-99 to 250
Resolution (ºC) 0.01
Therm Accuracy (± ºC)
2
0.05
3
AD560 Accuracy (± ºC)
2
0.05
LM335 Accuracy (± ºC)
2
0.05
RTD Accuracy (± ºC)
2
0.05
Stability (1hr) (± ºC)
4
0.004
Stability (24hr) (± ºC)
4
0.01
CURRENT
Range (A) 5
Compliance Voltage (V) 12
Max Power (W) 60
Resolution (A) 0.01
Accuracy (±[% set+mA]) 0 + 30
Noise/Ripple (mA, rms) < 5
MEASUREMENT
CURRENT
Resolution (mA) 10
Accuracy (±[% read+mA]) 0 + 30
VOLTAGE
Resolution (m
V
) 10
Accuracy (±[% read
V
]) 0 + 0.05
10μA THERMISTOR
Range (kΩ)
0.2 – 450
Resolution (kΩ)
0.01
Accuracy (±[% read+kΩ]) 0.05 + 50
100μA THERMISTOR
Range (kΩ)
0.02 – 45
Resolution (kΩ)
0.001
Accuracy (±[% read+kΩ]) 0.05 + 5
LM335
Bias (mA)
1
Range (mV)
1730 – 4730
Resolution (mV)
0.1
Accuracy (±[% read+m
V
]) 0.3 + 1
AD590
Bias (V)
4.5
Range (μA)
173 – 473
Resolution (μA)
0.01
Accuracy (±[% read+ μA])
0.03 + 0.1
RTD
Range (Ω)
20 – 192
Resolution (Ω)
0.01
1
Software limits. Actual range dependent on sensor type and system dynamics
2
Accuracy figures are the additional error the 5300 adds to the measurement, and does not include the
sensor uncertainties.
3
25°C, 100μA thermistor
4
Stability measurements done at 25°C using a 10kΩ thermistor on the 100μA setting. The number is ½
the peak-to-peak deviation from the average over the measurement period.
