3. Look from the tail after finished
2. Attach the control stick on the elevator
control horn.
-10-
Turn your transmitter on. Attach main battery to
airplane. Set the control stick not throttle stick on the
transmitter to the neutral (centered) position. Set the
control stick (throttle) all the way down. Adjust all trim
Tabs on the transmitter to neutral. Now adjust both
clevises in metal control rods coming out of plane to
ensure that a neutral setting is achieved when attaching
to control horn on both rudder and elevator. When
testing the throttle make sure to have a firm grip on the
plane.
Attaching Clevises to Control Hor n
Main wing
Attach the aileron servo into channel 1 on the receiver. Make sure polarity is correct otherwise
servo will not function. Observe the colored wires on the installed servos for guidance.
4Channel Version only
