use of bent bananas is necessary to avoid the handle of the test plug. From our experience we
recommend using the security strap of the Stäubli Electrical Connectors Multi-Contact Right-
angle adapter XWA-4/19 Ref. 66.9694. Page 71.
Plug Covers
A set of plug plastic covers is supply with the test plug, which is
recommended to place in the plugs where you want to avoid banana
connections. These covers are compatible for all the plugs.
It is advisable to place covers on the circuits that are used for
protection supply, to avoid errors in the protection power supply.
These can be removed if in the protection a new power supply is
required.
These plug covers must be removed or put by qualified personnel.
